Features
1. New Insulation Displacement and Crimping Ideas.
1.1 By using the IDC contact and crimping contact together,
different current capacity cables can be mixed in one case.
1.2 After connection, the contact can be replaced for excellent
maintenance.
1.3 The case protects the insulation displacement area for high
reliability.
1.4 Since the insulation displacement process can be performed only
by replacing the applicator of the existing crimping machine, no
expensive machinery for insulation displacement is required
2. Potting Header Available
3. Wide Variety
Connector Details
| TYPE | DESCRIPTION |
| Category | Connectors, Interconnects
Rectangular Connectors - Housings |
| Mfr | Hirose Electric Co Ltd |
| Series | DF1B |
| Package | Bulk |
| Part Status | Active |
| Connector Type | Receptacle |
| Connector Style | Female Socket |
| Number of Positions | 6 |
| Pitch | 0.098" (2.50mm) |
| Number of Rows | 1 |
| Mouting Type | Free Hanging (In-Line) |
| Contact Termination | Crimp, IDC |
| Color | White |
| Note | Contacts Not Included |
| Base Product Number | DF1B |
Product Specification
| Part No. | HRS No. | No. of Pos. |
| DF1B 2S-2.5R | CLO541-0200-6-00 | 2 |
| DF1B 3S-2.5R | CLO541-0201-9-00 | 3 |
| DF1B 4S-2.5R | CLO541-0202-1-00 | 4 |
| DF1B 5S-2.5R | CLO541-0203-4-00 | 5 |
| DF1B 6S-2.5R | CLO541-0204-7-00 | 6 |
| DF1B 7S-2.5R | CLO541-0205-0-00 | 7 |
| DF1B 8S-2.5R | CLO541-0206-2-00 | 8 |
| DF1B 9S-2.5R | CLO541-0207-5-00 | 9 |
| DF1B 10S-2.5R | CLO541-0208-8-00 | 10 |
| DF1B 11S-2.5R | CLO541-0209-0-00 | 11 |
| DF1B 12S-2.5R | CLO541-0210-0-00 | 12 |
| DF1B 13S-2.5R | CLO541-0211-2-00 | 13 |
| DF1B 14S-2.5R | CLO541-0212-5-00 | 14 |
| DF1B 15S-2.5R | CLO541-0213-8-00 | 15 |
| DF1B 16S-2.5R | CLO541-0214-0-00 | 16 |
| DF1B 18S-2.5R | CLO541-0215-3-00 | 18 |
| DF1B 20S-2.5R | CLO541-0216-6-00 | 20 |
Wire &Cable Reference
| Wire & cable information |
| German standard |
| FLRY-B | 0.35/0.5/0.75/1.5/2.5/4.0 |
| Japanese standard |
| TXL | 22AWG/20AWG/18AWG/16AWG/14AWG |
| GXL | 22AWG/20AWG/18AWG/16AWG/14AWG |
| UL |
| UL1007 | UL1061 | UL1015 |
| UL1569 | UL3239 | UL1430 |
| UL | | |
| UL2464 | UL20276 | UL2586 |
| UL2733 | | |
| Jacket material |
| PVC | PE | TPU |
| PU | TPE | XLPE |
| PUR | PTFE | Silicon rubber |
| | |
| External protective materials |
| PA flexible bellows |
| PP bellows |
| TPE Nylon Braided reticulated tube |
| Electrical tape |
| High temperature resistant flannel tape |
| PVC sleeve |
| Heat shrinkable tube |
