SPECIFICATIONS
1.Silver-plated contacts:
(1)Offer significant cost savings over gold-plating and avoid the
need to manually lubricate
tin-plated versions to mitigate fretting corrosion
2.50A interconnect solution:
(1)Supports high-power server, telecommunication, and industrial
equipment requirements
3.Polarized housing prevents connector mis-mating
4.Dual-beam (female) terminal design:
(1)Gives four points of contact and ensures superb contact
reliability
5.Terminal Position Assurance (TPA) retainer required on housings
prevents terminal back-out
| Mini Fit Sr 42816 10.0mm Latch Lock Connector for Custom Wire
Harness |
| Categories | Connectors, Interconnects |
| Rectangular Connectors - Housings |
| Manufacturer | Molex |
| Series | Mini-Fit Sr 42816 |
| Packaging | Bulk |
| Part Status | Active |
| Connector Type | Receptacle |
| Contact Type | Female Socket |
| Number of Positions | 2 |
| Pitch | 0.394" (10.00mm) |
| Number of Rows | 1 |
| Mounting Type | Free Hanging (In-Line) |
| Contact Termination | Crimp |
| Fastening Type | Latch Lock |
| Color | Black |
| Note | Contacts Not Included |
| Base Part Number | 42816 |
Documents & Media
| Datasheets | 42816-0x12 |
| 42815-001 Series Prod Spec |
| Product Training Modules | Power Connectors |
| Video File | Mini-Fit Sr |
| Other Related Documents | Mini-Fit Sr Test Summary |
| Environmental Information | 428160212 RoHS Cert of Compliance |
| PCN Assembly/Origin | 0428160y12 Production Location 21/Nov/2016 |
| HTML Datasheet | 42815-001 Series Prod Spec |
| PCN Other | Multiple Devices Shipping Location 20/Mar/2020 |
| Featured Product | Mini-Fit Sr. Power Connectors |
